GALVANISED 6 X 19 FC

A versatile, medium-lay rope with six outer strands of ~19 wires over a fibre core.

The fibre core improves flexibility and shock absorption, ideal where sheave diameters are modest and handling comfort is important. Heavy galvanising ensures long service life in marine conditions. Available in grades 1570, 1770, 1960 MPa. Stock: 10–16 mm. Ocean Force is a leading Australian supplier of Galvanised Wire Rope 6 x 19 FC.

Applications

  • Flexible, good fatigue life on sheaves.
  • Fibre core retains lubrication & cushions shock.
  • Hot-dip galvanised for marine resistance.
  • Splicing & swaging on-site up to 26 mm; NATA proof load available.
  • Manufactured to ISO 2408 / EN 12385; slings per AS 1666.
  • Versatile for winches, slings, lifting, and mooring. FC type is more flexible for rigging; IWRC is used for heavier load-bearing applications.
  • Specifications
  • Ask A Question
Nominal Diameter (mm) Minimum Breaking Load (Metric Ton) - FC Minimum Breaking Load (Metric Ton) - IWRC (180Kg/nm, 1770 N/nm) Minimum Breaking Load (Metric Ton) - IWRC (200Kg/nm, 1960 N/nm) Approx Weight (Kg/m) - FC Approx Weight (Kg/m) - IWRC
6 2.1 2.3 2.5 0.13 0.14
7 2.8 3.2 3.5 0.17 0.19
8 3.7 4.2 4.6 0.23 0.25
9 4.7 5.5 5.9 0.29 0.32
10 5.8 6.6 7.1 0.36 0.4
11 7.1 8.0 8.6 0.44 0.49
12 8.4 9.5 10.4 0.52 0.58
13 9.9 11.2 12.1 0.61 0.68
14 11.5 13.2 14.2 0.71 0.79
16 15.0 17.1 18.4 0.93 1.04
18 19.0 21.5 23.2 1.18 1.31
20 23.5 26.6 28.7 1.46 1.62
22 28.4 32.2 34.8 1.76 1.95
24 33.8 38.3 41.5 2.1 2.33
26 39.7 45.0 48.5 2.46 2.74

Measurements in tables may vary between different models. Ocean Force strives to ensure accuracy but encourages customers to contact us with any questions.
